Submersible Cable (1.5mm to 6mm)
3-core flat submersible pump cable, flexible copper, water-resistant, 1.5–6 sq mm.
- Conductor
- Electrolytic annealed copper, Class 5 flexible
- Construction
- 3-core flat (red / yellow / blue)
- Insulation
- PVC (IS 5831 Type A)
Overview
About the Submersible Cable (1.5mm to 6mm)
Flat 3-core cable for connecting submersible pump motors in borewells and wells. Flexible Class-5 electrolytic copper conductors (red / yellow / blue) are PVC-insulated and enclosed in a tough, water-resistant black PVC sheath to IS 694, rated up to 1100 V at 70°C. The flat profile runs neatly beside the riser pipe; supplied in 100 m coils. Sizes 1.5, 2.5, 4 and 6 sq mm.
Features
Key features
Water-resistant sheath for submerged use
Flexible fine-stranded copper
Flat profile for borewell runs
1100 V grade, IS 694 compliant
Supplied in 100 m coils
Specifications
Technical specifications
Specifications
| Conductor | Electrolytic annealed copper, Class 5 flexible |
| Construction | 3-core flat (red / yellow / blue) |
| Insulation | PVC (IS 5831 Type A) |
| Sheath | Black PVC, water-resistant |
| Voltage grade | Up to & incl. 1100 V |
| Temperature rating | 70°C |
| Size range | 1.5, 2.5, 4, 6 sq mm |
| Standard | IS 694 / IS 8130 / IS 5831 |
Material of Construction
Parts & materials
| Part name | Material |
|---|---|
| Conductor | Electrolytic copper |
| Insulation & sheath | PVC compound |
Applications
Where it's used
Submersible pump motor connections
Borewell & deep-well pumps
Irrigation & agricultural pumps
Water-supply pumping systems
